Standard Resin Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Anti-Aliasing Level	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon P1 Max	0.05 mm	2 s	2 s	20 s	1	16	5 mm	3 mm/s	3 mm/s
Photon P1	0.05 mm	2 s	2 s	20 s	1	4	5 mm	3 mm/s	3 mm/s
Photon Mono M7 Max	0.05 mm	2 s	0.5 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Pro	0.1 mm	2.2 s	0.5 s	25 s	3	1	4 mm	15 mm/s	15 mm/s
Photon Mono M7 Pro	0.05 mm	2 s	0.5 s	25 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7	0.05 mm	2.2 s	0.5 s	25 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono 4 Ultra	0.05 mm	2.6 s	1 s	30 s	5	1	5 mm	8 mm/s	8 mm/s
Photon Mono 4	0.05 mm	2.8 s	1 s	30 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono M5s Pro	0.05 mm	3.6 s	0.5 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5s	0.05 mm	2.8 s	0.5 s	25 s	5	1	5 mm	5 mm/s	6 mm/s
Photon Mono M5	0.05 mm	2.8 s	0.5 s	25 s	5	1	8 mm	5 mm/s	6 mm/s
Photon Mono X6Ks	0.05 mm	2.5 s	0.5 s	20 s	5	1	8 mm	3 mm/s	4 mm/s
Photon Mono X 6K	0.05 mm	2 s	0.5 s	23 s	6	1	8 mm	2 mm/s	3 mm/s
Photon M3 Max	0.05 mm	3 s	2.5 s	50 s	6	1	10 mm	2 mm/s	3 mm/s
Photon M3 Premium	0.05 mm	2.5 s	0.5 s	25 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono 2	0.05 mm	2.5 s	1 s	25 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono X2	0.05 mm	2.5 s	0.5 s	20 s	5	1	8 mm	2 mm/s	3 mm/s
Photon Mono 4K	0.05 mm	2 s	0.5 s	40 s	6	1	6 mm	4 mm/s	6 mm/s

Standard Resin V2 Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Anti-Aliasing Level	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon P1 Max	0.05 mm	2 s	2 s	20 s	1	16	5 mm	3 mm/s	3 mm/s
Photon P1	0.05 mm	2 s	2 s	20 s	1	4	5 mm	3 mm/s	3 mm/s
Photon Mono M7 Max	0.05 mm	2 s	0.5 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Pro	0.1 mm	2.2 s	0.5 s	25 s	3	1	4 mm	15 mm/s	15 mm/s
Photon Mono M7 Pro	0.05 mm	2 s	0.5 s	25 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7	0.05 mm	2.2 s	0.5 s	25 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono 4 Ultra	0.05 mm	2.6 s	1 s	30 s	5	1	5 mm	8 mm/s	8 mm/s
Photon Mono 4	0.05 mm	2.8 s	1 s	30 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono M5s Pro	0.05 mm	3.6 s	0.5 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5s	0.1mm	3s	0.5 s	25 s	6	1	5 mm	20 mm/s	20 mm/s
Photon Mono M5s	0.05 mm	2.8 s	0.5 s	25 s	5	1	8 mm	5 mm/s	6 mm/s
Photon Mono M5	0.05 mm	2.8 s	0.5 s	25 s	5	1	8 mm	5 mm/s	6 mm/s
Photon Mono X6Ks	0.05 mm	2.5 s	0.5 s	20 s	5	1	8 mm	3 mm/s	4 mm/s
Photon Mono X 6K	0.05 mm	2 s	0.5 s	23 s	6	1	8 mm	2 mm/s	3 mm/s
Photon M3 Max	0.05 mm	3 s	2.5 s	50 s	6	1	10 mm	2 mm/s	3 mm/s
Photon M3 Premium	0.05 mm	2.5 s	0.5 s	25 s	2	1	8 mm	6 mm/s	6 mm/s
Photon Mono 2	0.05 mm	2.5 s	1 s	25 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono X2	0.05 mm	2.5 s	0.5 s	20 s	5	1	8 mm	2 mm/s	3 mm/s
Photon Mono 4K	0.05 mm	2 s	0.5 s	40 s	6	1	6 mm	4 mm/s	6 mm/s

16K Standard Resin (Orange Red) Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Anti-Aliasing Level	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon P1 Max	0.05 mm	2.8 s	2 s	20 s	1	16	5 mm	3 mm/s	3 mm/s
Photon P1	0.05 mm	2.8 s	2 s	30 s	1	4	5 mm	3 mm/s	3 mm/s
Photon Mono M7	0.05 mm	2.8 s	0.5 s	80 s	15	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Pro	0.05 mm	2.8 s	0.5 s	80 s	15	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Max	0.05 mm	2.8 s	0.5 s	80 s	15	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5	0.05 mm	2.8 s	0.5 s	60 s	10	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5s	0.05 mm	3 s	0.5 s	60 s	10	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5s Pro	0.05 mm	3.6 s	1 s	60 s	12	1	8 mm	6 mm/s	6 mm/s
Photon Mono 4	0.05 mm	2.8 s	0.5 s	60 s	8	1	6 mm	4 mm/s	6 mm/s
Photon Mono 4K	0.05 mm	2.5 s	0.5 s	60 s	10	1	6 mm	4 mm/s	6 mm/s
Photon Mono 4 Ultra	0.05 mm	2.5 s	0.5 s	50 s	6	1	5 mm	8 mm/s	8 mm/s
Photon Mono 2	0.05 mm	2.5 s	1 s	60 s	12	1	6 mm	4 mm/s	6 mm/s
Photon Mono X2	0.05 mm	2.5 s	0.5 s	60 s	12	1	8 mm	2 mm/s	3 mm/s
Photon Mono X 6K	0.05 mm	2.5 s	0.5 s	80 s	12	1	8 mm	2 mm/s	3 mm/s
Photon Mono X 6Ks	0.05 mm	2.5 s	0.5 s	80 s	10	1	8 mm	2 mm/s	3 mm/s
ANYCUBIC Photon Mono M3 Max	0.05 mm	3 s	2 s	80 s	12	1	10 mm	4 mm/s	4 mm/s
ANYCUBIC Photon Mono M3 Premium	0.05 mm	2.5 s	0.5 s	60 s	10	1	8 mm	6 mm/s	6 mm/s

16K Standard Resin (Other 4 Colors) Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Anti-Aliasing Level	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon P1 Max	0.05 mm	2.5 s	2 s	20 s	1	16	4 mm	3 mm/s	3 mm/s
Photon P1	0.05 mm	2.5 s	2 s	20 s	1	4	5 mm	3 mm/s	3 mm/s
Photon Mono M7	0.05 mm	2.3 s	0.5 s	40 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Pro	0.05 mm	2 s	0.5 s	40 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Max	0.05 mm	2.5 s	0.5 s	45 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5	0.05 mm	2.8 s	0.5 s	40 s	6	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5s	0.05 mm	3 s	0.5 s	40 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5s Pro	0.05 mm	3.6 s	1 s	40 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono 4	0.05 mm	2.8 s	0.5 s	45 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono 4K	0.05 mm	2 s	0.5 s	40 s	6	1	6 mm	4 mm/s	6 mm/s
Photon Mono 4 Ultra	0.05 mm	2.5 s	0.5 s	40 s	5	1	5 mm	8 mm/s	8 mm/s
Photon Mono 2	0.05 mm	2.5 s	1 s	40 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono X2	0.05 mm	2.5 s	0.5 s	40 s	5	1	8 mm	2 mm/s	3 mm/s
Photon Mono X 6K	0.05 mm	2 s	0.5 s	45 s	6	1	8 mm	2 mm/s	3 mm/s
Photon Mono X 6Ks	0.05 mm	2.5 s	0.5 s	45 s	6	1	8 mm	2 mm/s	3 mm/s
ANYCUBIC Photon Mono M3 Max	0.05 mm	3 s	2 s	50 s	6	1	10 mm	4 mm/s	4 mm/s
ANYCUBIC Photon Mono M3 Premium	0.05 mm	2.5 s	0.5 s	45 s	3	1	8 mm	6 mm/s	6 mm/s

Water-Wash ABS-like Resin 3.0 Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Anti-Aliasing Level	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon P1 Max	0.05 mm	2.3 s	2 s	20 s	1	16	5 mm	3 mm/s	3 mm/s
Photon P1	0.05 mm	2 s	2 s	25 s	1	4	5 mm	3 mm/s	3 mm/s
Photon Mono M7	0.05 mm	2.2 s	0.5 s	25 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Pro	0.05 mm	2 s	1 s	25 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Max	0.05 mm	2 s	0.5 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5	0.05 mm	2.8 s	1 s	30 s	5	1	8 mm	5 mm/s	6 mm/s
Photon Mono M5s	0.05 mm	2.8 s	1 s	30 s	5	1	8 mm	5 mm/s	6 mm/s
Photon Mono M5s Pro	0.05 mm	3.2 s	1 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono 4	0.05 mm	2.4 s	1 s	30 s	5	1	5 mm	8 mm/s	8 mm/s
Photon Mono 4K	0.05 mm	2 s	1 s	40 s	6	1	6 mm	4 mm/s	6 mm/s
Photon Mono 4 Ultra	0.05 mm	3 s	1 s	35 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono 2	0.05 mm	2.5 s	1 s	25 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono X2	0.05 mm	2.5 s	1 s	25 s	5	1	8 mm	4 mm/s	4 mm/s
Photon Mono X 6K	0.05 mm	2 s	1 s	30 s	6	1	8 mm	2 mm/s	3 mm/s
Photon Mono X6Ks	0.05 mm	2.5 s	1 s	20 s	5	1	8 mm	3 mm/s	4 mm/s
Photon M3 Max	0.05 mm	3 s	2 s	35 s	6	1	10 mm	4 mm/s	4 mm/s
Photon M3 Premium	0.05 mm	2.5 s	1 s	35 s	5	1	8 mm	6 mm/s	6 mm/s

Water-Wash Resin 2.0 Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Anti-Aliasing Level	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon P1 Max	0.05 mm	2 s	2 s	30 s	1	16	5 mm	3 mm/s	3 mm/s
Photon P1	0.05 mm	2 s	2 s	30 s	1	4	5 mm	3 mm/s	3 mm/s
Photon Mono M7	0.05 mm	2.5 s	1 s	35 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Pro	0.05 mm	2 s	0.5 s	25 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Max	0.05 mm	2 s	0.5 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5	0.05 mm	2.8 s	0.5 s	25 s	5	1	8 mm	5 mm/s	6 mm/s
Photon Mono M5s	0.05 mm	2.8 s	0.5 s	25 s	5	1	8 mm	5 mm/s	6 mm/s
Photon Mono M5s Pro	0.05 mm	3.6 s	0.5 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono 4	0.05 mm	2.4 s	1 s	30 s	5	1	5 mm	8 mm/s	8 mm/s
Photon Mono 4K	0.05 mm	2 s	0.5 s	40 s	6	1	6 mm	4 mm/s	6 mm/s
Photon Mono 4 Ultra	0.05 mm	3 s	1 s	35 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono 2	0.05 mm	2.5 s	1 s	25 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono X2	0.05 mm	2.5 s	0.5 s	20 s	5	1	8 mm	2 mm/s	3 mm/s
Photon Mono X 6K	0.05 mm	2 s	0.5 s	23 s	6	1	8 mm	2 mm/s	3 mm/s
Photon Mono X6Ks	0.05 mm	2.5 s	0.5 s	20 s	5	1	8 mm	3 mm/s	4 mm/s
ANYCUBIC Photon M3 Max	0.05 mm	3 s	2 s	35 s	6	1	10 mm	2 mm/s	3 mm/s
ANYCUBIC Photon M3 Premium	0.05 mm	2.5 s	0.5 s	25 s	4	1	8 mm	6 mm/s	6 mm/s

ABS-Like Resin Pro 2 Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Anti-Aliasing Level	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon P1 Max	0.05 mm	2 s	2 s	25 s	1	16	5 mm	3 mm/s	3 mm/s
Photon P1	0.05 mm	2 s	2 s	25 s	1	4	5 mm	3 mm/s	3 mm/s
Photon Mono M7 Max	0.05 mm	2 s	0.5 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Pro	0.05 mm	2 s	1 s	25 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7	0.05 mm	2.2 s	1 s	35 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono 4 Ultra	0.05 mm	2.6 s	1 s	30 s	5	1	5 mm	8 mm/s	8 mm/s
Photon Mono 4	0.05 mm	2.8 s	1 s	30 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono M5s Pro	0.05 mm	3.6 s	1 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5s	0.05 mm	3 s	0.5 s	25 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5	0.05 mm	2.8 s	0.5 s	25 s	6	1	8 mm	6 mm/s	6 mm/s
Photon Mono X6Ks	0.05 mm	2.5 s	0.5 s	20 s	6	1	8 mm	2 mm/s	3 mm/s
Photon Mono X 6K	0.05 mm	2 s	0.5 s	23 s	6	1	8 mm	2 mm/s	3 mm/s
Photon M3 Max	0.05 mm	3 s	2 s	30 s	6	1	10 mm	4 mm/s	4 mm/s
Photon M3 Premium	0.05 mm	2.5 s	0.5 s	25 s	3	1	8 mm	6 mm/s	6 mm/s
Photon Mono 2	0.05 mm	2.5 s	1 s	28 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono X2	0.05 mm	2.5 s	0.5 s	25 s	5	1	8 mm	2 mm/s	3 mm/s
Photon Mono 4K	0.05 mm	2 s	0.5 s	40 s	6	1	6 mm	4 mm/s	6 mm/s

ABS-Like Resin 3.0 Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Anti-Aliasing Level	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon P1 Max	0.05 mm	2 s	2 s	25 s	1	16	5 mm	3 mm/s	3 mm/s
Photon P1	0.05 mm	2 s	2 s	25 s	1	4	5 mm	3 mm/s	3 mm/s
Photon Mono M7 Max	0.05 mm	3.2 s	0.5 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Pro	0.05 mm	2 s	1 s	25 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7	0.05 mm	2.2 s	1 s	35 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono 4 Ultra	0.05 mm	2.6 s	1 s	30 s	5	1	5 mm	8 mm/s	8 mm/s
Photon Mono 4	0.05 mm	2.8 s	1 s	30 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono M5s Pro	0.05 mm	3.6 s	1 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5s	0.05 mm	3 s	0.5 s	25 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5	0.05 mm	2.8 s	0.5 s	25 s	6	1	8 mm	6 mm/s	6 mm/s
Photon Mono X6Ks	0.05 mm	2.5 s	0.5 s	20 s	6	1	8 mm	2 mm/s	3 mm/s
Photon Mono X 6K	0.05 mm	2 s	0.5 s	23 s	6	1	8 mm	2 mm/s	3 mm/s
Photon M3 Max	0.05 mm	3 s	2 s	30 s	6	1	10 mm	4 mm/s	4 mm/s
Photon M3 Premium	0.05 mm	2.5 s	0.5 s	25 s	3	1	8 mm	6 mm/s	6 mm/s
Photon Mono 2	0.05 mm	2.5 s	1 s	28 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono X2	0.05 mm	2.5 s	0.5 s	25 s	5	1	8 mm	2 mm/s	3 mm/s
Photon Mono 4K	0.05 mm	2 s	0.5 s	40 s	6	1	6 mm	4 mm/s	6 mm/s

ABS-Like Resin 2.0 Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Anti-Aliasing Level	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon P1 Max	0.05 mm	2 s	2 s	25 s	1	16	5 mm	3 mm/s	3 mm/s
Photon P1	0.05 mm	2 s	2 s	25 s	1	4	5 mm	3 mm/s	3 mm/s
Photon Mono M7	0.05 mm	2 s	1 s	28 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Pro	0.05 mm	2 s	0.5 s	30 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Max	0.05 mm	2 s	0.5 s	28 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5	0.05 mm	2.8 s	0.5 s	25 s	6	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5s	0.05 mm	3 s	0.5 s	25 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5s Pro	0.05 mm	3.6 s	1 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono 4	0.05 mm	2.8 s	1 s	32 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono 4K	0.05 mm	2 s	0.5 s	40 s	6	1	6 mm	4 mm/s	6 mm/s
Photon Mono 4 Ultra	0.05 mm	2.6 s	0.5 s	32 s	5	1	5 mm	8 mm/s	8 mm/s
Photon Mono 2	0.05 mm	2.5 s	1 s	28 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono X2	0.05 mm	2.5 s	0.5 s	25 s	5	1	8 mm	2 mm/s	3 mm/s
Photon Mono X 6K	0.05 mm	2 s	0.5 s	23 s	6	1	8 mm	2 mm/s	3 mm/s
Photon Mono X 6Ks	0.05 mm	2.5 s	0.5 s	20 s	6	1	8 mm	2 mm/s	3 mm/s
ANYCUBIC Photon Mono M3 Max	0.05 mm	3 s	2 s	30 s	6	1	10 mm	4 mm/s	4 mm/s
ANYCUBIC Photon Mono M3 Premium	0.05 mm	2.5 s	0.5 s	25 s	3	1	8 mm	6 mm/s	6 mm/s

DLP Craftsman Resin Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Anti-Aliasing Level	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon P1 Max	0.05 mm	2.1 s	2 s	35 s	1	16	5 mm	3 mm/s	3 mm/s
Photon P1	0.05 mm	2.1 s	2 s	35 s	1	4	5 mm	3 mm/s	3 mm/s
Photon Mono M7	0.05 mm	2.2 s	0.5 s	25 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Pro	0.05 mm	1.8 s	0.5 s	40 s	3	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Max	0.05 mm	2 s	0.5 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5	0.05 mm	2.8 s	0.5 s	25 s	5	1	8 mm	5 mm/s	6 mm/s
Photon Mono M5s	0.05 mm	2.8 s	0.5 s	25 s	5	1	8 mm	5 mm/s	6 mm/s
Photon Mono M5s Pro	0.05 mm	3.6 s	0.5 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono 4	0.05 mm	2.8 s	1 s	30 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono 4 Ultra	0.05 mm	2.6 s	1 s	30 s	5	1	5 mm	8 mm/s	8 mm/s
Photon Mono 2	0.05 mm	2.5 s	1 s	25 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono X2	0.05 mm	2.5 s	0.5 s	20 s	5	1	8 mm	2 mm/s	3 mm/s
Photon Mono X 6K	0.05 mm	2 s	0.5 s	40 s	8	1	8 mm	2 mm/s	3 mm/s
Photon Mono X6Ks	0.05 mm	2.5 s	1 s	20 s	5	1	8 mm	2 mm/s	3 mm/s
ANYCUBIC Photon M3 Max	0.05 mm	3 s	2.5 s	35 s	6	1	8 mm	3 mm/s	4 mm/s
Photon M3 Premium	0.05 mm	2.5 s	0.5 s	25 s	4	1	8 mm	6 mm/s	6 mm/s

14K Texture Resin Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Anti-Aliasing Level	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon P1 Max	0.05 mm	2 s	2 s	25 s	1	16	5 mm	3 mm/s	3 mm/s
Photon P1	0.05 mm	2 s	2 s	25 s	1	4	5 mm	3 mm/s	3 mm/s
Photon Mono M7 Max	0.05 mm	2 s	0.5 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Pro	0.05 mm	2 s	1 s	25 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7	0.05 mm	2.2 s	0.5 s	25 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono 4 Ultra	0.05 mm	3 s	1 s	35 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono 4	0.05 mm	2.4 s	1 s	30 s	5	1	5 mm	8 mm/s	8 mm/s
Photon Mono M5s Pro	0.05 mm	3.2 s	1 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5s	0.05 mm	2.8 s	1 s	30 s	5	1	8 mm	5 mm/s	6 mm/s
Photon Mono M5	0.05 mm	2.8 s	1 s	30 s	5	1	8 mm	5 mm/s	6 mm/s
Photon Mono X6Ks	0.05 mm	2.5 s	1 s	20 s	5	1	8 mm	3 mm/s	4 mm/s
Photon Mono X 6K	0.05 mm	2 s	1 s	30 s	6	1	8 mm	2 mm/s	3 mm/s
Photon M3 Max	0.05 mm	3 s	2 s	35 s	6	1	10 mm	4 mm/s	4 mm/s
Photon M3 Premium	0.05 mm	2.5 s	1 s	35 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono 2	0.05 mm	2.5 s	1 s	25 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono X2	0.05 mm	2.5 s	1 s	25 s	5	1	8 mm	4 mm/s	4 mm/s
Photon Mono 4K	0.05 mm	2 s	1 s	40 s	6	1	6 mm	4 mm/s	6 mm/s

Plant-Based UV Resin 2.0 Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Anti-Aliasing Level	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon P1 Max	0.05 mm	2 s	2 s	20 s	1	16	5 mm	3 mm/s	3 mm/s
Photon P1	0.05 mm	2 s	2 s	20 s	1	4	5 mm	3 mm/s	3 mm/s
Photon Mono M7	0.05 mm	2.5 s	1 s	35 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Pro	0.05 mm	2 s	0.5 s	25 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Max	0.05 mm	2 s	0.5 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5	0.05 mm	2.8 s	0.5 s	25 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5s	0.05 mm	2.8 s	0.5 s	25 s	5	1	8 mm	5 mm/s	6 mm/s
Photon Mono M5s Pro	0.05 mm	3.6 s	0.5 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono 4	0.05 mm	2.4 s	1 s	30 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono 4K	0.05 mm	2 s	0.5 s	40 s	6	1	6 mm	4 mm/s	6 mm/s
Photon Mono 4 Ultra	0.05 mm	2 s	1 s	30 s	5	1	5 mm	8 mm/s	8 mm/s
Photon Mono 2	0.05 mm	2.5 s	1 s	25 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono X2	0.05 mm	2.5 s	0.5 s	20 s	5	1	8 mm	2 mm/s	3 mm/s
Photon Mono X 6K	0.05 mm	2 s	0.5 s	23 s	6	1	8 mm	2 mm/s	3 mm/s
Photon Mono X 6Ks	0.05 mm	2.5 s	0.5 s	20 s	5	1	8 mm	3 mm/s	4 mm/s
ANYCUBIC Photon Mono M3 Max	0.05 mm	3 s	2.5 s	35 s	6	1	10 mm	2 mm/s	3 mm/s
ANYCUBIC Photon Mono M3 Premium	0.05 mm	2.5 s	0.5 s	25 s	4	1	8 mm	6 mm/s	6 mm/s

Tough Resin 2.0 Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Anti-Aliasing Level	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon P1 Max	0.05 mm	2.1 s	2 s	15 s	1	16	5 mm	3 mm/s	3 mm/s
Photon P1	0.05 mm	2.1 s	2 s	15 s	1	4	5 mm	3 mm/s	3 mm/s
Photon Mono M7	0.05 mm	2.2 s	0.5 s	25 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Pro	0.05 mm	1.8 s	0.5 s	25 s	3	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Max	0.05 mm	2 s	0.5 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5	0.05 mm	2.8 s	0.5 s	25 s	5	1	8 mm	5 mm/s	6 mm/s
Photon Mono M5s	0.05 mm	2.8 s	0.5 s	25 s	5	1	8 mm	5 mm/s	6 mm/s
Photon Mono M5s Pro	0.05 mm	3.6 s	0.5 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono 4	0.05 mm	2.8 s	1 s	30 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono 4K	0.05 mm	2 s	0.5 s	40 s	6	1	6 mm	4 mm/s	6 mm/s
Photon Mono 4 Ultra	0.05 mm	2.6 s	1 s	30 s	5	1	5 mm	8 mm/s	8 mm/s
Photon Mono 2	0.05 mm	2.5 s	1 s	25 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono X2	0.05 mm	2.5 s	0.5 s	20 s	5	1	8 mm	2 mm/s	3 mm/s
Photon Mono X 6K	0.05 mm	2 s	0.5 s	25 s	6	1	8 mm	2 mm/s	3 mm/s
Photon Mono X6Ks	0.05 mm	2.5 s	0.5 s	20 s	5	1	8 mm	3 mm/s	4 mm/s
ANYCUBIC Photon M3 Max	0.05 mm	3 s	2.5 s	35 s	6	1	10 mm	2 mm/s	3 mm/s
ANYCUBIC Photon M3 Premium	0.05 mm	2.5 s	0.5 s	25 s	2	1	8 mm	6 mm/s	6 mm/s

Tough Resin Ultra Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Anti-Aliasing Level	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon P1 Max	0.05 mm	2.1 s	2 s	23 s	1	16	5 mm	3 mm/s	3 mm/s
Photon P1	0.05 mm	2 s	2 s	23 s	1	4	5 mm	3 mm/s	3 mm/s
Photon Mono M7	0.05 mm	2.2 s	1 s	25 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Pro	0.05 mm	2 s	2 s	25 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Max	0.05 mm	2 s	0.5 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5	0.05 mm	2.8 s	1 s	25 s	5	1	8 mm	5 mm/s	6 mm/s
Photon Mono M5s	0.05 mm	2.8 s	1 s	25 s	5	1	8 mm	5 mm/s	6 mm/s
Photon Mono M5s Pro	0.05 mm	3.6 s	1 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono 4	0.05 mm	2.8 s	1 s	30 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono 4K	0.05 mm	2 s	1 s	40 s	6	1	6 mm	4 mm/s	6 mm/s
Photon Mono 4 Ultra	0.05 mm	2.6 s	1 s	30 s	5	1	5 mm	8 mm/s	8 mm/s
Photon Mono 2	0.05 mm	2.5 s	1 s	25 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono X2	0.05 mm	2.5 s	1 s	20 s	5	1	8 mm	2 mm/s	3 mm/s
Photon Mono X 6K	0.05 mm	2 s	1 s	28 s	6	1	8 mm	2 mm/s	3 mm/s
Photon Mono X6Ks	0.05 mm	2.5 s	1 s	20 s	5	1	8 mm	3 mm/s	4 mm/s
Photon M3 Max	0.05 mm	3 s	2 s	35 s	6	1	10 mm	2 mm/s	3 mm/s
Photon M3 Premium	0.05 mm	2.5 s	1 s	25 s	2	1	8 mm	6 mm/s	6 mm/s

High Clear Resin Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Anti-Aliasing Level	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon P1 Max	0.05 mm	4.4 s	2 s	30 s	1	16	5 mm	3 mm/s	3 mm/s
Photon P1	0.05 mm	4.4 s	2 s	30 s	1	4	5 mm	3 mm/s	3 mm/s
Photon Mono M7	0.05 mm	4 s	1 s	35 s	4	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Pro	0.05 mm	3.5 s	0.5 s	35 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Max	0.05 mm	4 s	0.5 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5	0.05 mm	4 s	0.5 s	25 s	5	1	8 mm	5 mm/s	6 mm/s
Photon Mono M5s	0.05 mm	4 s	0.5 s	25 s	5	1	8 mm	5 mm/s	6 mm/s
Photon Mono M5s Pro	0.05 mm	4 s	0.5 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono 4	0.05 mm	4.5 s	1 s	30 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono 4K	0.05 mm	4 s	0.5 s	40 s	6	1	6 mm	4 mm/s	6 mm/s
Photon Mono 4 Ultra	0.05 mm	4.2 s	1 s	30 s	5	1	5 mm	8 mm/s	8 mm/s
Photon Mono 2	0.05 mm	4 s	1 s	25 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono X2	0.05 mm	4 s	0.5 s	25 s	5	1	8 mm	2 mm/s	3 mm/s
Photon Mono X 6K	0.05 mm	4 s	0.5 s	28 s	6	1	8 mm	2 mm/s	3 mm/s
Photon Mono X6Ks	0.05 mm	4 s	0.5 s	20 s	5	1	8 mm	3 mm/s	4 mm/s
Photon M3 Max	0.05 mm	4.5 s	2.5 s	30 s	6	1	10 mm	2 mm/s	3 mm/s
Photon M3 Premium	0.05 mm	4 s	0.5 s	25 s	3	1	8 mm	6 mm/s	6 mm/s

High Speed Resin 2.0 Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Anti-Aliasing Level	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon P1 Max	0.05 mm	1.1 s	2 s	15 s	1	16	5 mm	3 mm/s	3 mm/s
Photon P1	0.05 mm	1.5 s	2 s	15 s	1	4	5 mm	3 mm/s	3 mm/s
Photon Mono M7	0.1 mm	1.4 s	0.5 s	15 s	5	1	4 mm	15 mm/s	15 mm/s
Photon Mono M7 Pro	0.1 mm	1.4 s	0.5 s	15 s	5	1	4 mm	15 mm/s	15 mm/s
Photon Mono M7 Max	0.1 mm	1.8 s	0.5 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5	0.1 mm	2 s	0.5 s	25 s	5	1	8 mm	5 mm/s	6 mm/s
Photon Mono M5s	0.1 mm	2.8 s	0.5 s	25 s	5	1	8 mm	5 mm/s	6 mm/s
Photon Mono M5s Pro	0.1 mm	3.6 s	0.5 s	30 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono 4	0.1 mm	2.2 s	1 s	30 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono 4K	0.1 mm	2 s	0.5 s	25 s	6	1	5 mm	4 mm/s	6 mm/s
Photon Mono 4 Ultra	0.1 mm	2 s	1 s	30 s	5	1	5 mm	8 mm/s	8 mm/s
Photon Mono 2	0.1 mm	2.5 s	0.5 s	18 s	5	1	5 mm	4 mm/s	6 mm/s
Photon Mono X2	0.1 mm	2.5 s	0.5 s	18 s	5	1	6 mm	2 mm/s	6 mm/s
Photon Mono X 6K	0.1 mm	2 s	0.5 s	18 s	6	1	6 mm	4 mm/s	6 mm/s
Photon Mono X6Ks	0.1 mm	2.5 s	0.5 s	15 s	5	1	6 mm	4 mm/s	6 mm/s
ANYCUBIC Photon M3 Max	0.1 mm	2 s	0.5 s	18 s	5	1	5 mm	4 mm/s	6 mm/s
ANYCUBIC Photon M3 Premium	0.1 mm	1.5 s	0.5 s	18 s	5	1	6 mm	6 mm/s	6 mm/s

BJD Wear-Resistant Resin Recommended Printing Parameters

Printer Model	Layer Thickness	Exposure Time	Light-Off Time	Bottom Exposure Time	Bottom Layers	Anti-Aliasing Level	Z Lift Distance	Z Lift Speed	Z Retract Speed
Photon P1 Max	0.05 mm	2.4 s	2 s	20 s	1	16	5 mm	3 mm/s	3 mm/s
Photon P1	0.05 mm	2.2 s	2 s	30 s	1	4	5 mm	3 mm/s	3 mm/s
Photon Mono M7	0.05 mm	2 s	0.5 s	40 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Pro	0.05 mm	2 s	0.5 s	40 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M7 Max	0.05 mm	2 s	0.5 s	45 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5	0.05 mm	2.8 s	0.5 s	35 s	6	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5s	0.05 mm	3 s	0.5 s	35 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono M5s Pro	0.05 mm	3.6 s	1 s	40 s	5	1	8 mm	6 mm/s	6 mm/s
Photon Mono 4	0.05 mm	2.8 s	0.5 s	35 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono 4K	0.05 mm	2 s	0.5 s	40 s	6	1	6 mm	4 mm/s	6 mm/s
Photon Mono 4 Ultra	0.05 mm	2.5 s	0.5 s	35 s	5	1	5 mm	8 mm/s	8 mm/s
Photon Mono 2	0.05 mm	2.5 s	1 s	40 s	5	1	6 mm	4 mm/s	6 mm/s
Photon Mono X2	0.05 mm	2.5 s	0.5 s	40 s	5	1	8 mm	2 mm/s	3 mm/s
Photon Mono X 6K	0.05 mm	2 s	0.5 s	35 s	6	1	8 mm	2 mm/s	3 mm/s
Photon Mono X 6Ks	0.05 mm	2.5 s	0.5 s	35 s	6	1	8 mm	2 mm/s	3 mm/s
ANYCUBIC Photon Mono M3 Max	0.05 mm	3 s	2 s	30 s	6	1	10 mm	4 mm/s	4 mm/s
ANYCUBIC Photon Mono M3 Premium	0.05 mm	2.5 s	0.5 s	40 s	3	1	8 mm	6 mm/s	6 mm/s

Anycubic Resin User Manual & MSDS

Anycubic Resin User Manual

Filaments SDS

PLA

PLA High Speed

PLA+

PLA Silk

PLA Metal

PETG

PLA Matte

PLA Glow

ABS

TPU 95A

TPU 68D

ASA

PLA Marble

PLA Galaxy

PET-CF

PLA-CF

PETG-CF

PVA

PA6-CF

PLA Translucent

UV Resin MSDS

Standard Resin

Standard Resin V2

16K Standard Resin

Water-Wash ABS-Like Resin 3.0

Water-Wash 2.0

ABS-Like Resin Pro 2

ABS-Like Resin 3.0

ABS-Like Resin 2.0

DLP Craftsman Resin

14K Texture Resin

Plant-Based Resin 2.0

Tough Resin 2.0

Tough Resin Ultra

High Clear Resin

High Speed Resin 2.0

BJD Wear-Resistant Resin

Standard Resin Recommended Printing Parameters

Standard Resin V2 Recommended Printing Parameters

16K Standard Resin (Orange Red) Recommended Printing Parameters

16K Standard Resin (Other 4 Colors) Recommended Printing Parameters

Water-Wash ABS-like Resin 3.0 Recommended Printing Parameters

Water-Wash Resin 2.0 Recommended Printing Parameters

ABS-Like Resin Pro 2 Recommended Printing Parameters

ABS-Like Resin 3.0 Recommended Printing Parameters

ABS-Like Resin 2.0 Recommended Printing Parameters

DLP Craftsman Resin Recommended Printing Parameters

14K Texture Resin Recommended Printing Parameters

Plant-Based UV Resin 2.0 Recommended Printing Parameters

Tough Resin 2.0 Recommended Printing Parameters

Tough Resin Ultra Recommended Printing Parameters

High Clear Resin Recommended Printing Parameters

High Speed Resin 2.0 Recommended Printing Parameters

BJD Wear-Resistant Resin Recommended Printing Parameters

Subscribe to our emails
